:, and each key gets a grid row with its type, TTL, length, and value. The editor takes Redis commands, one per statement, and passes them through as written. Redis needs no plugin: its hiredis-based driver is part of the app, and it reaches standalone servers, Sentinel-managed primaries, and Redis Cluster.
Quick setup
1
Create Connection
Click New Connection…, select Redis, and enter host, port, password, and database index
2
Test Connection
Click Test Connection, then Save & Connect
Connection settings
No minimum server version. ACL users need Redis 6, a Sentinel ACL user needs 6.2, and Cluster mode reads routing tips from Redis 7 where they exist.
The sidebar then lists one entry per database,
db0 upward, counted from the server’s own CONFIG GET databases. ElastiCache, Azure Cache for Redis and Memorystore refuse CONFIG, and so do ACL users without config|get; those servers are listed as 16 databases, or up to the highest one INFO keyspace names as holding keys. A key count left blank means the server would not answer INFO for your user. Click a database to browse it in place, which is also how the database index changes after connecting.
Connection URL
rediss:// connects with TLS. See Connection URL Reference.
Authentication
The Username field selects a Redis 6 ACL user. Empty signs in asdefault, the identity a bare requirepass password belongs to.
A username is sent as AUTH username password even when Password is empty, which is the form a nopass ACL user needs. Every other user rejects that form, so the connection either holds the identity typed into the form or fails.
A nopass user accepts any password, so a leftover value in Password still signs in as that user.
Connection modes
Standalone
The default. One server, named by Host and Port.Sentinel
For a deployment fronted by Redis Sentinel. The quorum says which node is primary and the data connection opens there; a failover is read from the quorum on the next health check and the connection moves itself. A demoted primary keeps answeringrole:master and keeps accepting writes for several seconds, and those writes are lost, so the quorum is the only signal worth trusting.
Host and Port are ignored here. Username and Password under Authentication belong to the primary; Sentinel is a separate plane with its own. The rest of the quorum is discovered at connect and remembered, so a lookup still works once the node you listed goes down. If none can be reached, or none monitors the group you named, the error lists the addresses tried and the groups they do monitor.
Cluster
For a sharded Redis Cluster. The shard map is read withCLUSTER SHARDS, or CLUSTER SLOTS on Redis 6; a connection opens to every primary and each command goes to the shard that owns its key.
DBSIZE is summed across shards, browsing merges their keys into one tree, and MGET, MSET, DEL, EXISTS, TOUCH and UNLINK are split per shard and recombined. When one shard refuses its part, or cannot answer because it is loading or busy running a script, the command reports that shard’s error instead of a partial total. Redis cannot undo the part of a split write that already ran, so the error lists the keys it changed, or for FLUSHDB the nodes. A shard that denies DBSIZE leaves the sidebar key count blank, and on a cluster with more than one database each count is INFO keyspace summed across primaries. A MOVED re-points the slot and retries, an ASK retries against the importing node, and one command follows at most five redirects. What Cluster mode cannot do is under Limitations.
The wrong mode is caught at connect, on Valkey as on Redis: Standalone against a cluster member, or any data mode against a Sentinel port, names the field to change.
Amazon ElastiCache (IAM)
Set Authentication to an AWS IAM mode (Access Key, Profile, or SSO). A short-lived IAM token becomes the Redis password and the username is your IAM-enabled Redis user. Enter the AWS region and the cache name (replication group ID), and turn TLS on, which ElastiCache IAM requires. Profiles resolve from~/.aws/config and ~/.aws/credentials, credential_process, SSO, and assumed roles included.
Browsing keys
user:1 and user:2 sit under a user folder, nested as deep as the key goes (app:cache:session:1). Change the separator on the Options tab. When the tree cannot load, the server’s error takes its place; right-click Keys and choose Refresh to try again.
Keys grouped by namespace with type-aware values
A value that is not valid UTF-8, such as a gzip or MessagePack payload, opens in the hex editor instead of as text.
A Type, TTL, Length or Value cell is NULL when the server will not say for your user. ACL key patterns do not filter
SCAN, so a user limited to ~app:* still sees every key name, and editing Value is skipped for a key whose Type is NULL.
Editing
Editing a Key cell runsRENAME. Editing a TTL cell runs EXPIRE, or PERSIST when you set it to -1; in that column -1 means no expiry and -2 means the key is gone. Editing a Value cell runs SET, and only on a string, since a preview of a hash or list is not the whole structure.
Change the other types with a command: HSET myhash field1 "value1" rewrites one field and leaves the rest alone. Adding a row does follow the type you pick, generating HSET, RPUSH, SADD, ZADD, or SET.
Filtering
Toggle the filter bar to search keys by pattern. Patterns are Redis glob (* any sequence, ? one character, [ae] a character set) and case-sensitive, as in redis-cli. The type scope narrows to String, Hash, List, Set, Sorted Set, or Stream. Matching runs server-side with SCAN MATCH and SCAN TYPE.
Redis CLI
Each statement is one command; separate several with;. Commands the driver does not recognize go through too, and only the result formatting is type-aware. A recognized command with arguments its result view does not model, such as FLUSHDB ASYNC or CONFIG SET a 1 b 2, is also sent exactly as typed, so the server answers it as redis-cli would. Arguments are quoted the way redis-cli quotes them, so " and ' both work and \xHH writes a raw byte; unbalanced quotes are rejected rather than guessed at. Redis has no comment syntax and none is stripped, so a -- or # line is sent to the server and fails.
SELECT moves the editor’s session only. The commands after it run on that database, while the sidebar, the key tree and the database tab stay on the database you clicked. Clicking a database moves the editor to that database.
DB 3 GET key runs one command on database 3 and leaves the session where it was. A key opened from the tree is read this way, and so are grid saves on a cluster.
MULTI blocks
A command sent afterMULTI answers QUEUED instead of its own reply, and nothing runs until EXEC. EXEC then returns every reply in order, errors included; an error element reads (error) WRONGTYPE …, the way redis-cli prints one.
The rest of the app reads the same session, so while the block is open it sends nothing of its own on it. The sidebar, the key browser, the key tree and a database click say the block is open instead, and the connection check skips its PING. Run EXEC or DISCARD to get them back. Saving grid edits is refused while keys are watched; run EXEC, DISCARD or UNWATCH first.
If the connection drops while a block is open or keys are watched, the server discards both. The next command reports the lost block or WATCH instead of running on the new session, and an EXEC the connection dropped under reports that whether the block ran is unknown.
SSL/TLS
Set this in the SSL/TLS pane. Upstash, Redis Cloud and the like require TLS;rediss:// turns it on when importing a URL.
New connections default to Disabled. SNI is sent in every TLS mode.
Limitations
- A command that fails while
EXECis running cannot be taken back. Standalone and Sentinel wrap a grid save inMULTI/EXEC, so the rest of the block stays applied and the error names the one that failed; check the keys it touched. A command refused before it runs, for a missing ACL permission, a fullmaxmemoryor wrong arity, aborts the block and writes nothing. - No transactions in Cluster mode. Grid saves run their commands one at a time, so a failure leaves the earlier ones applied. Deleting grid rows sends one
DELper hash slot, and Save Incomplete counts how many ran. Group keys under one hash tag if they must move together. - A
SELECTtyped inside aMULTIblock waits forEXEC, and never happens at all after aDISCARD. Clicking a database in the sidebar while a block is open is refused; close the block first. - A service with one database, such as Upstash or Redis Cloud, refuses
CONFIG, so the sidebar lists 16. Every database butdb0shows the server’s error when you click it. - Redis Cluster serves database 0 only, and so does Valkey unless
cluster-databasesis above 1, in which case the sidebar lists each database. A cluster whose primaries refuseCONFIGshowsdb0alone. The Database Index field is hidden in Cluster mode, and a cluster connection always opens ondb0. - A command whose keys span hash slots, such as
RENAME,SMOVE, or the*STOREcommands, is refused in Cluster mode before it is sent. Give the keys a shared hash tag, like{user}:1and{user}:2. - A key that is not valid UTF-8 never appears in the grid or the tree. Reach it from the CLI; values have no such limit.
- Pub/Sub has no grid support.
PUBLISHruns in the CLI, and there is no subscriber view. - The sidebar tree loads at most 50,000 keys and a filter scans at most 10,000 matches. Narrow the pattern, or
SCANfrom the CLI. - Values and TTLs cannot be filtered on. Redis has no server-side primitive for either; filter by key pattern and type only.
- No import. Export works as it does elsewhere.
Troubleshooting
NOPERM … has no permissions to run the ‘scan’ command
The ACL user cannot runSCAN, which the key tree and the key browser read keys with, and key types need TYPE. Grant both with ACL SETUSER <user> +scan +type, then right-click Keys and choose Refresh.
On iPhone and iPad the key list reads SCAN and TYPE too, and opening a key reads it by type: GET, LLEN and LRANGE, HLEN and HSCAN, SCARD and SSCAN, ZCARD and ZRANGE … WITHSCORES, or XLEN and XRANGE. A refusal there reads Permission Denied.
SELECT … failed: ERR DB index is out of range
The server has no database with that index. A server that refusesCONFIG is listed as 16 databases whatever it holds, so check databases in redis.conf or the service’s own limit, and browse a database the server has.
Connection refused
The server is not listening where the connection points. Check Redis is running (brew services start redis), the port matches redis.conf, and the bind directive covers the address you are using.
WRONGPASS invalid username-password pair or user is disabled.
The server rejected the pair. With Username empty,AUTH password is checked against the default user, and an ACL user’s password fails that: fill in Username to authenticate as that user. With Username filled and Password empty, the named user has a password and needs it, or the name does not exist on this server.
One ACL trap produces the same error: >password sets a password, #hash sets a SHA-256 hash, and a 64-character hex string is valid for both, so ACL SETUSER myuser on #<64-hex> is accepted where > was meant. ACL LIST prints passwords as hashes, so a value copied from there is a hash, not a password.
This server requires authentication.
The server answeredNOAUTH to the first command, so the connection carries no identity. Check requirepass in redis.conf and whether the default user is off in ACL LIST. Fill in Password, and Username as well when the account is an ACL user.
ERR wrong number of arguments for ‘auth’ command
The server predates Redis 6 and takes a password alone. Check its version withINFO server. Clear Username.
Timeout
Nothing answered in time. Verify host and port, check the network and firewall, and allow your IP on a cloud-hosted Redis.Sentinel or cluster mode over SSH
A tunnel forwards one local port to one remote address, and the addresses Sentinel and Cluster hand back are the server’s own. Over a tunnel only the first host in the list is used, as a standalone node, so failover and shard routing are unavailable.Slow key list
KEYS blocks the server on a large keyspace. Browse by namespace instead, and use SCAN in the CLI when you need a pattern. Check memory pressure with INFO memory.
