Appearance Settings

Configure how TablePro looks in Settings > Appearance.

​

Theme Engine

TablePro ships with 9 built-in themes and supports custom themes. Community themes are available from the plugin registry. Each theme controls editor syntax colors, data grid colors, sidebar/toolbar styling, fonts, spacing, and layout tokens.

​

Theme Editor Layout

The Appearance tab is a split view with two panels:

• Left panel: Sections for “Built-in”, “Registry”, and “Custom”. Each row shows a color thumbnail, theme name, and source label. Select a theme to activate and edit it.
• Right panel: Three tabs: Fonts, Colors, and Layout.

At the bottom of the sidebar, an action bar provides:

​

Built-in Themes

​

Theme Appearance Mode

Each theme has a fixed appearance property: light, dark, or auto. Activating a theme sets NSApp.appearance to match. One active theme at a time; there is no separate light/dark assignment.

​

Customizing Themes

Select a theme and edit directly. Built-in themes auto-duplicate when you change colors or layout, preserving the original. Font changes apply without duplication.

​

Import, Export & Registry

Export custom themes as JSON. Import from files or install from the plugin registry (Settings > Plugins > Browse, filter by Themes). Registry themes are read-only; duplicate to customize.

​

Connection Colors

Color-code connections for quick identification:

​

Setting Connection Color

1. Open the connection form (edit or create)
2. In the Appearance section, click Color
3. Select a color from the palette
4. Save the connection

​

Connection Color Display

Connection colors show up in:

• Sidebar connection list
• Tab headers
• Connection status bar
• Window title (when connected)

​

Database Type Colors

Each database type has a fixed color for quick identification: These appear on:

• Database type icons
• Connection type indicators
• Sidebar icons
