Cassandra / ScyllaDB Connections

TablePro supports Apache Cassandra 3.11+ and ScyllaDB 4.0+ via the CQL native protocol. Browse keyspaces, inspect table structures, view materialized views, and run CQL queries from the editor.

​
Quick setup

Click New Connection, select Cassandra or ScyllaDB, enter host/port/credentials/keyspace, and click Create.

​
Connection settings

FieldDefaultNotes
HostlocalhostCQL contact point
Port9042CQL native port
Keyspace-Leave empty for local dev
Username-Disable auth for local dev
Password-
See Connection URL Reference for URL format.

​
Example configurations

Local: host localhost:9042, no auth Docker: cassandra:latest, user/pass cassandra:cassandra DataStax Astra DB: Port 29042, use Client ID/Secret, needs Secure Connect Bundle (SSL/TLS) Remote: Use SSH tunneling for production SSL/TLS: Enable in connection form. Astra DB requires Secure Connect Bundle.

​
Features

Keyspace Browsing: Sidebar lists keyspaces with tables, materialized views, UDTs, secondary indexes. Click to view data. Table Structure: Columns (name, type, clustering order), partition key, clustering columns, secondary indexes, table options (compaction, compression, TTL, gc_grace_seconds). Materialized Views: Browse alongside tables. Shows definition, base table, column mappings. Data Grid: Pagination. Type-aware formatting: text (plain), int/bigint/varint (numbers), uuid/timeuuid (formatted), timestamp (configurable), map/set/list/tuple (formatted collections), blob (hex).

​
CQL editor

Execute CQL statements directly in the editor tab:
-- Select with partition key restriction
SELECT * FROM users WHERE user_id = 123e4567-e89b-12d3-a456-426614174000;

-- Insert data
INSERT INTO users (user_id, name, email, created_at)
VALUES (uuid(), 'Alice', '[email protected]', toTimestamp(now()));

-- Update with TTL
UPDATE users USING TTL 86400
SET email = '[email protected]'
WHERE user_id = 123e4567-e89b-12d3-a456-426614174000;

-- Delete
DELETE FROM users WHERE user_id = 123e4567-e89b-12d3-a456-426614174000;

-- Create table
CREATE TABLE IF NOT EXISTS events (
    event_id timeuuid,
    user_id uuid,
    event_type text,
    payload text,
    PRIMARY KEY ((user_id), event_id)
) WITH CLUSTERING ORDER BY (event_id DESC);

-- Create index
CREATE INDEX ON users (email);

-- Describe table
DESCRIBE TABLE users;

​
CQL-specific notes

No JOINs: Denormalize data across multiple tables instead. No subqueries: Break into multiple sequential statements. Partition Key Requirement: Every SELECT must include full partition key in WHERE, or use ALLOW FILTERING (cluster scan, slow in prod). ALLOW FILTERING Warning: Full cluster scan. OK for dev, not for production. TablePro shows warning. Lightweight Transactions: Conditional writes with IF: INSERT INTO users (...) IF NOT EXISTS; UPDATE users SET email = 'new' WHERE user_id = ? IF email = 'old'; TTL and Writetime: INSERT INTO cache (...) USING TTL 3600; SELECT TTL(value), WRITETIME(value) FROM cache WHERE key = 'k1';

​
Troubleshooting

Connection refused: Check Cassandra running (nodetool status), verify port 9042 in cassandra.yaml, check rpc_address and listen_address. Auth failed: Verify credentials, check authenticator: PasswordAuthenticator in cassandra.yaml. Default superuser: cassandra:cassandra Timeout: Verify host/port, check network/firewall (port 9042), whitelist IP for cloud-hosted, increase timeout in Advanced. Read timeout: Include full partition key in WHERE, remove ALLOW FILTERING, check cluster health with nodetool, use LIMIT. Limitations: Multi-DC not configurable, UDFs/UDAs in CQL but not sidebar, counter columns read-only (use editor), large partitions paginated. Performance: Include partition key, avoid ALLOW FILTERING in prod, use LIMIT, use TOKEN() for range scans.
