Elasticsearch Connections

TablePro connects to Elasticsearch 7.x and 8.x over the REST API. Browse indices as tables, run Query DSL requests in a Kibana-style console, page through documents in the data grid, and edit documents inline. Supports HTTP Basic auth, API keys, and TLS.

​
Quick Setup

Click New Connection, select Elasticsearch, enter host and port (default 9200), pick an auth method, and connect. The plugin auto-installs, or use Settings > Plugins > Browse > Elasticsearch Driver.

​
Authentication Methods

Username & Password: HTTP Basic auth. Enter the username and password in the standard connection fields. API Key: Paste a base64-encoded API key (the id:api_key pair encoded as base64, or the encoded value returned by the create API key request). Sent as the Authorization: ApiKey header. None: No authentication, for clusters with security disabled.

​
Connection Settings

​
Required Fields

FieldDescription
HostCluster host (e.g. localhost)
PortREST port, default 9200
Auth MethodUsername & Password, API Key, or None

​
Optional Fields

FieldDescription
SSLEnable to connect over HTTPS
Skip TLS VerificationTrust self-signed certificates (Advanced section). Elasticsearch 8.x ships with TLS on by default
API KeyBase64-encoded key, shown when Auth Method is API Key

​
Features

Index Browsing: The sidebar lists indices as tables. System and hidden indices (names starting with .) are hidden. Each index shows its documents in the grid, its fields in the structure view, and its mapping as DDL. Field Discovery: Columns come from the index mapping. Nested object and nested fields flatten into dotted paths (address.city). Documents always include the _id, _index, and _score meta columns; _id is the primary key. Array and object values render as JSON in the cell. Query DSL Console: The editor is a Kibana Dev Tools-style console. Write a method, a path, and an optional JSON body:
GET /my-index/_search
{
  "query": {
    "match": { "title": "search term" }
  }
}

GET /_cat/indices?format=json

POST /my-index/_doc
{
  "title": "New document",
  "views": 0
}
Search responses render as a grid; _cat and other array responses tabularize; everything else shows as formatted JSON. Filtering and Sorting: Column filters translate to Query DSL (term, range, wildcard, terms, exists). A raw filter (the default filter mode) is treated as an Elasticsearch query_string, so its text is Lucene syntax, for example name:Widget or price:>10, run across all fields. Sorting a text field automatically targets its .keyword subfield when one exists, since text fields are not directly sortable. Data Editing: Edit cells, insert documents, and delete documents. Edits map to REST operations keyed by _id: POST /index/_update/{id}, PUT /index/_doc/{id}, and DELETE /index/_doc/{id}. The _id, _index, and _score columns are read-only. Pagination: The grid pages with from/size up to the index max_result_window (default 10,000). Past that window, TablePro pages with search_after and a point-in-time (PIT) for deeper browsing.

​
Example Configurations

Local cluster: Host localhost, port 9200, Auth Method None (security disabled) or Username & Password. Elastic 8.x with TLS: Enable SSL, set Username & Password, and enable Skip TLS Verification if the cluster uses the default self-signed certificate. API key: Auth Method API Key, paste the base64-encoded key.

​
Troubleshooting

Authentication failed: Verify the username and password, or the API key. On 8.x, security and TLS are on by default. TLS errors: Enable SSL, and enable Skip TLS Verification for self-signed certificates. Sort not allowed on a text field: Sort on the field’s .keyword subfield, or add one to the mapping. Limitations: Read-only _sql is not exposed; use the Query DSL console. No schema editing, no transactions. Deep paging past max_result_window uses search_after and can drift under concurrent writes. Elasticsearch only (OpenSearch is not yet supported).
