DuckDB - TablePro

Pick a .duckdb file to open a database, or a .parquet, .csv, .tsv, .json or .ndjson file to read it where it sits. DuckDB 2.0.0 is compiled into the driver, so nothing runs as a server unless you point the connection at one. A .duckdb file the connection creates or attaches stays readable by DuckDB 1.x. The DuckDB driver is not in the app. Picking DuckDB in the Choose a Database sheet offers the download before the form opens, and opening a saved DuckDB connection installs it without asking. See Plugins.

Quick setup

Create the connection

Click New Connection… or press Cmd+N, then choose DuckDB.

Choose a file

Leave Connection Type on Local File and click Browse…, or New… to name a .duckdb file that does not exist yet. Type :memory: in the field instead for a database that lasts as long as the session.

Connect

Click Save & Connect.

What the file field accepts

Path	What you get
`.duckdb`, `.ddb`, or a DuckDB or SQLite file under any other name	The database in that file. A path that does not exist yet is created
`.parquet`, `.csv`, `.tsv`, `.json`, `.jsonl`, `.ndjson`, also gzip or zstd compressed	An in-memory database holding two read-only views over the file, one named `file` and one named after the file. A path that does not exist is reported instead of created
`:memory:`	An empty database, discarded on disconnect

In Local File mode the path is the whole connection, and it is required; the form shows no host, port or Database field, and no Network tab. Double-click a .duckdb or .ddb file in Finder to open it here. .parquet files list TablePro under Open With rather than taking the association; to make a double-click open them here, select one in Finder, press Cmd+I, set Open with to TablePro, and click Change All…. .csv, .tsv, .json and .ndjson open from the connection form only. A DuckDB database carries DUCK eight bytes in, so a database opens under any name: drag warehouse.db onto a window and it reaches this driver rather than SQLite. The data formats need their extension either way, because the reader is chosen from it. Installing the plugin is offered first when it is not already there.

Remote (Quack)

Quack is DuckDB’s client-server protocol, served by quack_serve. Set Connection Type to Remote (Quack, experimental):

Field	Value
Host	Server address. Required
Port	`9494` by default
Token	The token the server was started with, the `token` argument of `quack_serve`. Required
Database Alias	The name the remote is attached under. Pre-filled with `remotedb`
SSL Mode	Automatic by default. See SSL/TLS
CA Certificate	Under Verify Identity only. The PEM file of the CA that signed the server’s certificate. Optional
Certificate Fingerprint	Under Verify Fingerprint only. The SHA-256 fingerprint of the server’s certificate. Required

Save & Connect attaches the remote to an in-memory DuckDB. Reach it through the alias: SELECT * FROM remotedb.main.orders. Token, SSL Mode and the certificate fields are all the connection uses: a remote session reads no secret saved with CREATE PERSISTENT SECRET in ~/.duckdb/stored_secrets, so a token or pin stored there for the server has no effect. For a server this Mac cannot reach directly, Remote mode adds a Network tab with SSH Tunnel, Cloudflare Tunnel, SOCKS Proxy and Tunnel Command. Host and Port stay the server’s own, named as the far end of the tunnel reaches it: localhost for a server on the SSH server itself. Then pick the SSL Mode from Through a tunnel.

The macOS build links neither the quack extension nor httpfs, which carries HTTPS under every SSL Mode but Verify Fingerprint. DuckDB downloads each from extensions.duckdb.org the first time a connection needs it and caches it under ~/.duckdb, so that connect needs to reach that host.

Connection URL

duckdb:///path/to/database.duckdb
quack://host:9494/alias
quack://host:9494/alias?sslmode=verify-full
quack://host:9494/alias?ssl_fingerprint=4A:1F:9C:02:7E:B3:58:D6:11:E0:3C:A7:92:5B:F4:08:6D:21:C9:7A:E5:30:4F:B8:17:93:DA:6E:02:C5:8B:F1
quack+ssh://[email protected]/localhost:9494/alias

sslmode sets SSL Mode, ssl_fingerprint sets Verify Fingerprint and its pin, and a connection behind an SSH tunnel copies as quack+ssh://. DuckDB remote has every value.

Databases and schemas

A connection opens one database named after the file: analytics.duckdb becomes analytics, schema main. ATTACH a second file and it joins the sidebar as a sibling database after a refresh:

ATTACH 'warehouse.duckdb' AS warehouse;

Press Cmd+K to move between them, in place, with no reconnect. An ATTACH typed in the editor lasts until the next connect. To keep a file attached, add it under Attached Databases in the connection’s Options: every connect attaches it again, named after its file without the extension, and a file that is missing is named in a warning while the rest attach. With Open the File Read-Only on, they attach read-only as well. system and temp are hidden, and with them information_schema and pg_catalog. Any connection can also read a file straight from SQL:

SELECT * FROM 'data.csv';
SELECT * FROM read_parquet('analytics.parquet');

One process writes a DuckDB file at a time, and the lock lasts as long as the connection. While a tab is open on sales.duckdb, duckdb sales.duckdb in a terminal is refused, and so is a notebook, a dbt run, or a second TablePro window. Three ways out, in Options on the connection:

Setting	What happens	Pick this when
Release the File Lock After	The file is handed back once the connection has been idle that many minutes, and taken again on the next query. `0`, the default, keeps it	A script or a scheduled job needs the file while you are reading it
Open the File Read-Only	The file is opened read-only, which several processes can do at once. Writes are refused by the engine	Two or more readers, and nothing writing
Neither	The lock is held for the life of the connection	Nothing else touches the file

Database ▸ Release File Lock hands it back now, without ending the session. The tabs, the schema cache and the row you were on all stay; the next query takes the file again. A release is refused, with the reason, while the session holds anything reopening would destroy: an open transaction, a temporary table or view, a database attached from the editor, or a changed setting. The connection’s own Attached Databases attach again on reopen. Commit the transaction or drop the temporary table and the release goes through. Read-only is not a way to keep writing from somewhere else. A read-write connection blocks every other process, read-only ones included; a read-only connection blocks writers. Two readers work, a reader and a writer do not. Releasing hands the file to whoever wants it next, which may not be you. A query run after another process has taken it fails until that process lets go; reconnect once it has.

Back up and restore

File > Backup Dump… runs over the open connection. It copies the whole database into a .duckdb file, or exports it as a folder of Parquet files. File > Restore Dump… takes the .duckdb file. For the folder, and what each format carries, see Backup & Restore.

SSL/TLS

A local file has no TLS. A remote connection’s SSL Mode sits on the General tab with the other Remote fields and starts on Automatic. Leave it there unless the server’s certificate comes from a private CA or from quack_serve itself. No mode falls back to another: a mismatch stops the connect with a message naming the setting to change.

SSL Mode	What the connection does	Pick it for
Automatic	Plain HTTP to `localhost`, `127.0.0.1` and `::1`. HTTPS to any other host, with the certificate checked against `/etc/ssl/cert.pem` and the host name	A server on this Mac, or one with a public certificate
Disabled	Plain HTTP to any host	A plain HTTP server on another machine
Required (skip verify)	HTTPS, with no certificate check	Testing. The token goes to whichever server answers
Verify Identity	HTTPS, with the certificate checked against `/etc/ssl/cert.pem` plus CA Certificate, and the host name	A certificate from a private CA, such as one mkcert made
Verify Fingerprint	HTTPS, with the certificate matched against Certificate Fingerprint. No name is checked	The certificate `quack_serve` generates, or any self-signed one

Trusting a private CA

DuckDB never reads the macOS keychain. A CA trusted there, by mkcert -install or in Keychain Access, does not make its certificates pass under Automatic. Give DuckDB the CA file instead:

Find the CA file

Use the PEM certificate of the CA that signed the server’s. For mkcert that is rootCA.pem, in the folder this prints:

mkcert -CAROOT

Choose it

Set SSL Mode to Verify Identity, click Browse… beside CA Certificate, and choose the file.

The file has to be PEM. A DER file is refused before DuckDB dials the server; convert it with openssl x509 -inform der -in ca.der -out ca.pem. The connection then trusts that CA on top of /etc/ssl/cert.pem for every HTTPS read it makes, read_parquet('https://…') in its editor included. Other connections are unaffected. With CA Certificate left empty, Verify Identity checks against /etc/ssl/cert.pem alone, and uses HTTPS even to localhost.

Pinning the server’s certificate

Started without a certificate of its own, quack_serve generates one that names no host, so no CA check can pass it. Set SSL Mode to Verify Fingerprint and paste the certificate’s SHA-256 fingerprint into Certificate Fingerprint. On the server, the ssl_fingerprint column holds it:

FROM quack_server_list();

For a certificate file, openssl prints the same value:

openssl x509 -noout -fingerprint -sha256 -in cert.pem

The field takes the 64 hex digits with or without colons, and with or without sha256: in front. Once the server has a new certificate, the pin fails until you paste the new fingerprint.

Through a tunnel

A tunnel hands DuckDB a port on 127.0.0.1 in place of the server’s name, so no mode checks the certificate’s name there. Host on General still decides what Automatic does.

The server	SSL Mode
`quack_serve` on `localhost` where the tunnel lands, serving plain HTTP	Automatic, with Host set to `localhost`. Nothing off that machine reaches the server, and the tunnel encrypts the hop. Prefer this setup
HTTPS, on any host	Verify Fingerprint, or Required (skip verify) to encrypt without a check
Plain HTTP, on another host	Disabled

Verify Identity, and Automatic with any Host but localhost, 127.0.0.1 or ::1, are refused before DuckDB dials, with a message naming the modes that work.

Limitations

A DuckDB file takes one writer at a time. A connect against a file another process holds fails, naming that process and its process ID. Quit the duckdb CLI, the Python process or the other TablePro window first, or set Release the File Lock After.
A data file opened through Browse… is read-only, and the file on disk is left byte for byte identical. To change its contents, open a .duckdb database and run CREATE TABLE t AS SELECT * FROM 'data.parquet'.
Remote (Quack) lists no tables in the sidebar. Write them out by name through the alias.
Local File has no tunnel. To reach a file on another machine, serve it there with quack_serve and connect in Remote mode.
Quack takes no client certificate. Token is the only credential a remote connection sends.
A remote connection’s editor sees no persistent secret, an S3 one included, so a read that needs it fails. Run CREATE SECRET in the session instead; it lasts until the connection closes. Local File connections read persistent secrets.
Required (skip verify) turns the certificate check off for every HTTPS read the connection makes, read_parquet('https://…') in the editor included. Pin the server with Verify Fingerprint to keep those reads checked.
No creating or dropping a database. ATTACH is the way to reach a second file.

Troubleshooting

No file at …

A data-file path that is not there. Only .duckdb and .ddb are created on demand. Re-pick the file with Browse….

DuckDB opened the file but reported no catalog to browse

The file opened and exposed nothing to list. Check that it is a DuckDB database and not a file with a borrowed extension.

… is using sales.duckdb

Another process holds the file. The message names it and its process ID. Quit it, or turn on Open the File Read-Only when the message says read-only would get in, which it does when the other process is itself a reader.

The database file is no longer at …

The file moved or was deleted while the connection was idle with its lock released. Point the connection at the new path, or restore the file, then reconnect.

Token is required

Token is empty, and every Quack server has one. Find the token argument quack_serve was started with on the server, and enter it in Token. A token saved as a persistent DuckDB secret is not read.

Port must be a number between 1 and 65535

Port holds something else. The Quack default is 9494.

This connection sets SSL Mode, which the installed DuckDB driver does not support yet

The loaded DuckDB driver is older than SSL Mode, and this connection sets a mode other than Automatic, so it is refused before anything is dialed. After an app update the new driver downloads in the background and loads at the next launch. Check the driver’s row in Settings > Extensions, relaunch once it reads “Updates when TablePro relaunches”, then connect again. Updates has the details.

DuckDB could not install its … extension

The first remote connect downloads quack, and httpfs for HTTPS, from extensions.duckdb.org, and this Mac could not reach that host. DuckDB’s own reason follows the message. Allow the host through the firewall or proxy, then connect again; once installed, the extension loads with no network.

DuckDB could not verify the server’s certificate

The server’s certificate was signed by a CA that neither /etc/ssl/cert.pem nor CA Certificate holds, or it names another host. A CA trusted only in the macOS keychain counts as neither. Choose the CA file under Verify Identity, or pin the certificate under Verify Fingerprint, as SSL/TLS shows.

The server uses HTTPS, and this connection sent plain HTTP

SSL Mode is Disabled, or Automatic with a local Host, and the server speaks TLS. Set it to Verify Identity, or to Verify Fingerprint for a self-signed certificate. Through a tunnel, use Verify Fingerprint or Required (skip verify).

The server did not answer the TLS handshake

The connection used HTTPS, and the server serves plain HTTP or is not a Quack server. Check how quack_serve was started. For plain HTTP, set SSL Mode to Disabled.

The server’s certificate does not match the Certificate Fingerprint

The server now presents a different certificate from the one pinned, or another server answered. Read ssl_fingerprint again from FROM quack_server_list(); on the server and paste it into Certificate Fingerprint.

The Certificate Fingerprint is not a SHA-256 fingerprint

Certificate Fingerprint holds something other than 64 hex digits, a 40-digit SHA-1 fingerprint for instance. Copy it again from quack_server_list(), or from openssl x509 -noout -fingerprint -sha256 -in cert.pem.

The CA Certificate at … is not a PEM certificate

The file under CA Certificate is DER, or not a certificate at all. Convert a DER file with openssl x509 -inform der -in ca.der -out ca.pem, then choose ca.pem.

TablePro could not read the CA Certificate at …

The file moved, or its permissions keep it from being read. The reason follows the path. Choose the file again with Browse….

DuckDB could not read the CA Certificate

The file under CA Certificate starts like PEM, and DuckDB still rejected it. Check that it holds whole -----BEGIN CERTIFICATE----- blocks, or export the CA again as PEM.

Verify Identity does not work through a tunnel

SSL Mode is Verify Identity and the Network tab has a tunnel selected. DuckDB dials the tunnel on 127.0.0.1, so the certificate would be checked against that rather than the server’s name. Set SSL Mode to Verify Fingerprint, or to Required (skip verify).

Automatic does not work through a tunnel to …

Host is not localhost, 127.0.0.1 or ::1, so Automatic would use HTTPS and check the certificate against 127.0.0.1. Set SSL Mode to Verify Fingerprint, Required (skip verify), or Disabled for a plain HTTP server. Or run quack_serve on localhost where the tunnel lands and set Host to localhost.

SSH Tunneling, for a remote server behind a bastion host
TablePro for iPhone and iPad, where DuckDB opens a file picked through the Files app
