Pairing

Pairing is how an extension gets a TablePro token without the user copying and pasting one. The user runs a Pair with TablePro command in the extension, picks scopes and connections inside TablePro, and the extension receives a token over a Raycast deep link callback. The flow is PKCE-flavored: the extension generates a verifier, hashes it into a challenge, and the token is only released after the verifier is presented. This prevents another app on the same machine from intercepting the redirect and stealing the token.

​
Sequence

​
Step by step

​
1. Extension generates a verifier and challenge

import { randomBytes, createHash } from "node:crypto";

function base64url(buffer: Buffer): string {
  return buffer.toString("base64").replace(/\+/g, "-").replace(/\//g, "_").replace(/=+$/, "");
}

const verifier = base64url(randomBytes(32));
const challenge = base64url(createHash("sha256").update(verifier).digest());
The verifier is 32 random bytes, base64url-encoded. Keep it in memory until the exchange step. Do not log it.
import { open } from "@raycast/api";

const params = new URLSearchParams({
  client: `Raycast on ${require("os").hostname()}`,
  challenge,
  redirect: "raycast://extensions/ngoquocdat/tablepro/pair-callback",
  scopes: "readOnly,readWrite",
});
await open(`tablepro://integrations/pair?${params}`);
See the URL scheme reference for parameters.

​
3. TablePro shows the approval sheet

The user sees:
  • The client name from the request.
  • A scopes radio (defaults to the requested scope, downgradeable).
  • A connections multi-select (defaults to all unless connection-ids was provided).
  • An expiry picker (defaults to never).
The user can change any of these before approving. The query parameters are a request, not a grant.

​
4. TablePro generates a token and a one-time code

On approval, TablePro calls MCPTokenStore.generate(...) to mint a token, then stores a pending exchange:
struct PendingExchange {
    let plaintextToken: String
    let challenge: String
    let expiresAt: Date  // now + 5 min
}
The plaintext token is held in memory only. The token store keeps the hashed form on disk (SHA-256 + salt).

​
5. TablePro redirects with the code

TablePro opens the redirect URL with NSWorkspace.shared.open(...). The encoding depends on the redirect scheme:
  • raycast://...: TablePro appends ?context={"code":"<uuid>"} (URL-encoded JSON). Raycast parses context and passes it to the receiving command as LaunchProps.launchContext. This matches Raycast’s documented launch-context convention.
  • Anything else (http://127.0.0.1:<port>/callback, custom schemes): TablePro appends ?code=<uuid> as a flat query parameter. Standard OAuth-callback shape.

​
6. Extension exchanges the code

The extension reads the MCP port from ~/Library/Application Support/TablePro/mcp-handshake.json, then:
const port = await readHandshakePort();
const res = await fetch(`http://127.0.0.1:${port}/v1/integrations/exchange`, {
  method: "POST",
  headers: { "Content-Type": "application/json" },
  body: JSON.stringify({ code, code_verifier: verifier }),
});
const { token } = await res.json();
The exchange endpoint requires no bearer auth. The single-use code is the auth.

​
7. TablePro validates and returns the token

Server-side check:
SHA-256(code_verifier) == challenge
If equal, return the plaintext token and delete the pending exchange. If the code has expired (5 minutes) or the verifier does not match, return 403.

​
8. Extension stores the token

import { LocalStorage } from "@raycast/api";
await LocalStorage.setItem("apiToken", token);
For preferences-backed storage, use updateCommandMetadata or write to the password preference. Tokens stored in Raycast preferences live in the macOS Keychain.

​
Security properties

PropertyHow
Token is never in the URLThe token is fetched over localhost HTTP, not embedded in a deep link.
Redirect interception is harmlessA malicious app that intercepts the code cannot exchange it without the verifier.
Code is single-useSuccessful exchange or 5-minute expiry deletes the pending exchange.
Plaintext token is not persisted by TableProOnly the SHA-256 hash plus salt is saved to mcp-tokens.json.
User sees and approves scopesThe sheet shows what was requested, what is granted, and which connections.
User can revoke any timeSettings > Integrations > Authentication > Revoke.

​
Errors

CodeMeaning
403 challenge mismatchThe verifier does not hash to the stored challenge.
404 pairing codeThe code does not exist or has already been exchanged.
410 expiredThe pending exchange is older than 5 minutes.
A failed exchange is recorded in the activity log under the auth category with outcome denied.

​
Implementing pairing in another extension

The flow is not Raycast-specific. Cursor, Claude Desktop, or any custom client can use it. Requirements:
  1. Generate a verifier and challenge.
  2. Open tablepro://integrations/pair?... with a deep link callback URL the OS can route back to the extension.
  3. Read the MCP port from the handshake file.
  4. POST { code, code_verifier } to /v1/integrations/exchange.
  5. Store the returned token in OS Keychain.
If the extension cannot register a custom URL scheme, open a localhost HTTP server on a chosen port and pass http://127.0.0.1:<port>/callback as the redirect.
